12.5 TR Tip table
TheinnovativechangeovernozzlefromTitan
combinestwonozzlecoresintoonenozzle.
TR Tip holder
Order no. 0271065
Application Tip marking
(1 / 2)
Spray angle
(1 / 2)
Bore 1
inch / mm
Bore 2
inch / mm
Spraying
width 1 mm *
Spraying
width 2 mm *
Gun lter Order no.
Cabinets, Furniture and
Decks
311/107
313/109
30º/10º
30º/10º
0.011 / 0.28
0.013 / 0.33
0.007 / 0.18
0.009 / 0.23
150
150
100
100
red
red
692-311
692-313
Doors & Trim 415/111
417/113
40º/10º
40º/10º
0.015 / 0.38
0.017 / 0.43
0.011 / 0.28
0.013 / 0.33
190
190
100
100
yellow
white
692-415
692-417
Exterior Latex or Oil 515/211 50º/20º 0.015 / 0.38 0.011 / 0.28 225 120 yellow 692-515
Exterior Latex 517/213
519/213
521/215
50º/20º
50º/20º
50º/20º
0.017 / 0.43
0.019 / 0.48
0.021 / 0.53
0.013 / 0.33
0.013 / 0.33
0.015 / 0.38
225
225
225
120
120
120
white
white
white
692-517
692-519
692-521
Blockller 535/223
635/327
50º/20º
60º/30º
0.035 / 0.90
0.035 / 0.90
0.023 / 0.58
0.027 / 0.69
225
270
120
150
green
green
692-535
692-635
Diluted joint compound 627/321
831/321
60º/30º
80º/30º
0.027 / 0.69
0.031 / 0.79
0.021 / 0.53
0.021 / 0.53
270
330
150
150
green
green
692-627
692-831
WideSpray Latex 1223/315
1231/317
120º/30º
120º/30º
0.023 / 0.58
0.031 / 0.79
0.015 / 0.38
0.017 / 0.43
540
540
150
150
white
white
692-1223
692-1231
Firestop 525/331 50º/30º 0.035 / 0.90 0.031 / 0.79 225 150 green 692-525331
12.6 Additional accessories for 560e
Order no. Description
580-050 LX-80 spray gun, hose and tip
580-100A LX-80 II spray gun with 517 tip
316-505 1/4”x50’airlesshose
314-482 LS-10 Liquid Shield™, 1 quart
314-480 PistonLube™,8oz.bottle
0508071 PaintMate, 1 quart
