5-62
Power Unit
4st 9.9/15/20 2008
4. When flywheel attached to power unit, put power head ass’y 1
upside down on the work bench, and install oil strainer 3.
Attach hose so that it is tilted to the direction shown by arrow
(45 degrees). As a guide, attach hose so that it is tilted toward
plunger 2.
Complete this work in a short period. Doing this
work for long time can cause engine oil to flow
from breather pipe.
44) Installing Flywheel
1. Install flywheel with flywheel engaged with crankshaft key.
2. Tighten flywheel nut to specified torque.
3. Install flywheel cover.
Flywheel Nut :
80 N · m (58 lb · ft) [8.0 kgf · m]
Flywheel puller ass’y :
P/N. 369-72211-0
E_MFS20C_ch05_090105.qxd 09.1.20 5:25 PM ページ 62
