5
5-61
4st 9.9/15/20 2008
7. Prepare for installation of rectifier.
Collect wires from rectifier as shown.
10. Secure wires w and carburetor breather hose e using
clamp r.
8. Install rectifier 0 to intake manifold.
9. Connect wire couplers, and bind them using lead wire band q
located on the rectifier.
11. Attach carburetor fuel hose t to fuel pump y.
Fix fuel hose to intake manifold by using clamp u.
Attach ground wire i from rectifier.
0
q
e
r
w
i
t
u
y
E_MFS20C_ch05_090105.qxd 09.1.20 5:25 PM ページ 61
