TOHATSU MFS 20C User Manual

Bracket
7-18
4st 9.9/15/20 2008
9) Installing Steering Shaft
1. Attach thrust plate 1 and bushing 2 to steering shaft.
2. Stand swivel bracket ass'y vertically, and insert steering
shaft into swivel bracket ass'y.
3. Attach bushing 3, new O ring 4, and thrust plate 5 to
swivel bracket.
2
1
3
4
5
3. Pull out steering shaft 2 from swivel bracket ass'y to
remove.
2
2. Loose co-pilot handle nut and remove handle 1.
1
E_MFS20C_ch07_081216.qxd 09.1.20 5:40 PM ページ 18
