TOHATSU MFS 4C Service Manual

5-18
Power Unit
4st 4/5/6 2011
5) Inspection of Crank Case Head
1. Check crank case head for crack, damage and corrosion.
Replace if necessary.
6) Assembly of Crank Case Head
1. Attach new oil seal 1 to crank case head by using a
commercially available mandrel. Apply lithium grease to
the lip of oil seal.
LIT
GREASE
LIT
1
7) Installation of Crank Case Head
1. Attach a new Gasket 1.
1
2. Install crank case head ass'y to cylinder block ass'y.
LIT
GREASE
LIT
Crank Case Head Bolt :
6 N · m (4 lb · ft) [0.6 kgf · m]
1
Do not reuse.
1
Do not reuse.
MFS4-5-6Ech05110425.qxd11.4.2511:39AM  ページ18
