TOHATSU MFS 4C Service Manual

7
7
Bracket
1. Parts Layout ……………………………… 7-2
Bracket & Reverse Lock ……………………… 7-2
Drive Shaft Housing & Shift ………………… 7-4
Bottom Cowl & Tiller Handle ………………… 7-6
Cowl …………………………………………… 7-8
2. Disassembling and Assembling
Procedure …………………………………… 7-9
1) Removal and inspection of drive
shaft housing ……………………………… 7-9
2) Removal and inspection of clamp bracket … 7-11
3) IInstallation of clamp bracket and
drive shaft ……………………………………… 7-12
4) Removal, inspection and installation of
water pipe ……………………………… 7-14
5) Remove, inspection and installation of
tiller handle ……………………………… 7-15
6) Adjustment of Throttle Cable ………… 7-18
