6-12
Lower Unit
4st 4/5/6 2011
7)
Disassembly of Propeller Shaft Housing
1. Remove bearing 1 by using commercially available bearing
puller.
2. Remove oil seal 2.
1 Bearing
Do not reuse.
8)
Inspection of Propeller Shaft Housing
1. Use cleaning oil and cleaning brush to clean propeller shaft
housing, and check it for crack or damage. Replace if
necessary.
2. Check reverse (C) gear teeth and clutch for crack or
damage. Replace if necessary.
2 Oil Seal
Do not reuse.
Do not reuse removed bearing.
Before removing, check bearing for play or
deflection. Replace if necessary.
When reusing bearing without removing it, check
it for play or deflection. Replace if necessary.
MFS4-5-6Ech06110422.qxd 11.4.22 5:50 PM ページ12
