TOHATSU MFS 4C Service Manual

5-26
Power Unit
4st 4/5/6 2011
15)Disassembly of Cylinder and oil pan
1. Loosen oil pan bolts in the order reverse to the numbers
shown, and remove oil pan
—
19
8
7
9
6
4
2
5
3
1
· Wipe off spilt oil completely.
· When tightening bolts, follow the numbers
shown.
2. Remove crankshaft washer 1 and then cam shaft 2.
11
22
3. Remove lifter 3.
33
4. Loosen cylinder head mounting bolts, and then remove
cylinder head.
1
4
2
3
Store “IN” side and “EX” side parts identifiably.
