5-28
Power Unit
4st 4/5/6 2011
16)Disassembly and Inspection of
Breather Chamber
1. Loosen breather cover mounting screws and then remove
the cover.
2. Remove two breather collars 1 and two wave washers 2,
check the parts, and replace if necessary.
17) Inspection of Lifter
1. Check lifter for bend and wear. Replace if necessary.
3. Attach breather collars 3 and wave washers 4.
Position breather collar so that the hole a is directed as
shown.
MFS4-5-6Ech05110425.qxd11.4.2511:39AM ページ28
