TOHATSU MFS 4C Service Manual

6-18
Lower Unit
4st 4/5/6 2011
2
3
2
4
3
5
6
3. Remove bearing 2.
Bearing Press 3 :
P/N. 3H6-72769-0
Bearing Press Collar 4 :
P/N. 3H6-72768-0
Center Plate 3 5 :
P/N. 3AB-99701-0
Driver Rod 3 6 :
P/N. 3AB-99702-0
2
Do not reuse.
2
3
2
7
1
23) Disassembly of Gear Case
1. Check bearings 1 for cracks and generation of abnormal
noise. Replace if necessary.
1
Do not reuse.
2. Remove bearing 1 by using commercially available bearing
puller.
· Do not remove bearing unless it is replaced
with new one.
· Before removing, check bearing for play or
deflection. Replace if necessary.
Do not reuse removed bearing.
CAUTION
Needle bearing press Ass'y 7 :
P/N. 369-72900-0
MFS4-5-6Ech06110422.qxd 11.4.22 5:50 PM  ページ18
