TOHATSU MFS 4C Service Manual

6
6-7
4st 4/5/6 2011
1-1 Gear Case Ass'y 1
1-2 Gear Case Ass'y 1 For 6ps UL
2 Roller Bearing 14-20-12 1
3 Plug 2
4 Gasket 8.1-15-1 2
5 Anode 1
6 Bolt 1 M6 L=16mm
7 Ball Bearing 6004 1
8 Propeller Shaft Housing Ass'y 1
9 Propeller Shaft Housing 1
10 Oil Seal 15-28-10 1
11 O-Ring 3.2-47 1
12 Ball Bearing 6002 1
13 Bevel Gear Ass'y (A) 1
14 Bevel Gear (B) 1
15 Bevel Gear Ass'y (C) 1
16 Washer 15.2-19-1.9 1
17-1 Shim 21-28-0.1 A
17-2 Shim 21-28-0.15 A
18 Propeller Shaft 1
19 Clutch 1
20 Pin 3.5-28 1
21 Spring Clutch 1
22 Spring Retainer Clutch 1
23 Push Rod Clutch 1
24 Water Strainer Sub 1
25 Screw 1 M6 L=20mm
26 Water Pipe (Lower) 1
27 Seal Rubber Water Pipe Lower 2
28 Water Pump Impeller 1
29 Key Pump Impeller 1
30 Pump Case (Upper) 1
31 Pump Case Liner 1
32 Water Pump Guide Plate 1
33 Pump Case Gasket 1
34 Guide Plate Gasket 1
35 Bolt 4 M6 L=45mm
36 Washer 4
37 Pump Case (Lower) 1
38 Oil Seal 10-24-8 1
39-1 Shim 28-34.8-0.1 A
39-2 Shim 26.5-34.8-0.15 A
40 Pump Case Gasket (Lower) 1
41 Bolt 1 M6 L=25mm
42 Water Pipe Seal (Lower) 1
43-1 Drive Shaft Ass'y (S) 1 For Transom "S"
43-2 Drive Shaft Ass'y (L) 1 For Transom "L"
43-3 Drive Shaft Ass'y (UL) 1 For Transom "UL"
44 Ball Bearing 6300 1
45 Clutch Cam 1
46 Spring Pin 3-10 1
47-1 Cam Rod (S) 1 For Transom "S"
47-2 Cam Rod (L) 1 For Transom "L"
47-3 Cam Rod (UL) 1 For Transom "UL"
48 Spring Pin 3-12 1
49 Bushing Camshaft 1
50 O-Ring A 2.5-4.9 1
51 O-Ring 2.4-15.4 1
52 Stopper Cam Rod Bushing 1
53 Grommet 2 For 6ps UL
54 Bolt 1 M6 L=45mm
55 Washer 1
56 Bolt 1 M8 L=35mm
57 Washer 1
58 Bolt 2 M6 L=16mm
59-1 Propeller Ass'y (6) Y 1 STD:Sail Pro
59-2 Propeller Ass'y (7) 1 STD:4ps "S,L"
59-3 Propeller Ass'y (8) 1 STD:5/6ps "S,L"
59-4 Propeller Ass'y (9) 1
60 Propeller Hardware Kit 1
61 Propeller Nut 1
62 Split Pin 3-18 1
63 Washer 10.5-28-2 1
64 Thrust Holder Ass'y 1
65-1 Water Pipe Ass'y (S) 1 For Transom "S"
65-2 Water Pipe Ass'y (L) 1 For Transom "L"
65-3 Water Pipe Ass'y (UL) 1 For Transom "UL"
66 Grommet Water Pipe Upper 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
