10-2
WIring Diagram
4st 4/5/6 2011
IGNITER
MAGNETO
W
B
-------
Black
Br
-----
Brown
R
-------
Light Green
W ------ White
Lg
-----
Light Green
F 4B/5B/6B
STOP SWITCH
Y
Y
MAGNETO
Y
Y
Y
Y
BATTERY
RECTIFIER
OPTION
ALTERNATOR
YR
YR
RB
Lg Lg W
FUSE
LIGHT EXTENSION CORD
WARNING LIGHT
OIL
PRESSURE
SWITCH
MFS4-5-6Ech10110422.qxd11.4.226:57PMページ2
