TOHATSU MFS 4C Service Manual

11-13
4st 4/5/6 2011
11
1 Cylinder Block 1
2 Oil Seal 20-35-7 1
3 Ball Bearing 6205 1
4 Breather Chamber Cover 1
5 Gasket Breather Chamber Cover 1
6 Collar Breather 2
7 Wave Washer d=5 2
8 Screw 2 M6 L=16mm
9 Bolt 1 M6 L=12mm
10 Oilpan Sub-Ass'y 1
11 Oil Seal 25-40-8 1
12 Grommet Oilpan 1
13 Dowel Pin 6-12 2
14 Oil Pump Rotor (Inner) 1
15 Oil Pump Rotor (Outer) 1
16 Pin Oil Pump 1
17 O-Ring Oil Pump Cover ø3.1 1
18 Oil Pump Cover 1
19 Bolt 6-16 3 M6 L=16mm
20 Plunger Control 1
21 Spring Pressure 1
22 Seat Spring 1
23 O-Ring 1.9-6.8 1
24 Plunger Cover 1
25 Drain Bolt 1
26 Washer 10.2-19-1 1
27 Strainer Body 1
28 Strainer Cap 1
29 Mesh Strainer 1
30 Pipe Strainer 1
31 Seal Rubber Strainer 2
32 Strainer Stopper 1
33 Screw 1 M5 L=12mm
34 Bolt 5-16 (Precoated) 2 M5
35 Washer 2
36 Oilpan Gasket 1
37 Exhaust Cover Gasket 1
38 Exhaust Cover (Inner) 1
39 Bolt 6-20 3 M6 L=20mm
40 Bolt 3 M6 L=40mm
41 Bolt 6 M8 L=40mm
42 Oil Pressure Switch 1
43 Grommet Oil Pressure Switch 1
44 Oil Pressure Switch Lead Wire L=390 1
45 Crankcase Head 1
46 Oil Seal 10.1-25-7 2
47 Spacer 19-24.8-1.0 1
48 Crankcase Head Gasket 1
49 Bolt 2 M6 L=20mm
50 Breather Hose 1
51 Clip ø12 2
52 Oil Level Gauge 1
53 O-Ring 2.62-18.72 1
54 Bolt Washer 1 M6 L=12mm
55 Clamp 6.5-47.5P 1
56 Clamp Holder 1
57 Clamp 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ13
