TOHATSU MFS 4C Service Manual

11-15
4st 4/5/6 2011
11
1 Cylinder Head Ass'y 1
2 Intake Valve 1
3 Exhaust Valve 1
4 Bolt 1 M6 L=35mm
5 Valve Spring Seat 2
6 Valve Spring L=35 2
7 Retainer 2
8Cotter 4
9 Dowel Pin 6-12 2
10 Cylinder Head Gasket 1
11 Cylinder Head Bolt 8-90 2
12 Cylinder Head Bolt 8-60 2
13 Exhaust Cover Gasket 1
14 Cylinder Head Cover 1
15 Cylinder Head Cover Gasket 1
16 Bolt 4 M6 L=16mm
17 Washer 6-16-1.5 4
18 Thermostat 1 Mark 5B or 52B
19 Thermostat Cap 1
20 Thermostat Cap Gasket 1
21 Camshaft Ass'y 1 Mark 6
22 Lifter 2
23 Push Rod 2
24 Plate Push Rod 1
25 Pivot Bolt 2
26 Rocker Arm 2
27 Pivot Rocker Arm 2
28 Adjusting Nut 2
29 Throttle Drum 1
30 Throttle Opener 1
31 Collar Drum 1
32 Washer 6-16-1.5 1
33 Bolt 2 M6 L=45mm
34 Throttle Rod 1
35 Spark Plug (DCPR6E) 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ15
