TOHATSU MFS 4C Service Manual

11-21
4st 4/5/6 2011
11
1-1 Flywheel MF54 (Mark48) 1 STD with out Alternator
1-2 Flywheel MF54 (Mark50) 1 for Sail Pro (with Alternater)
2 Alternator Ass'y 1 for Sail Pro 12V60W (with Alternater)
3 Screw 4 for Sail Pro (with Alternater) M5 L=25mm
4 Washer 4 for Sail Pro (with Alternater) M5
5Clamp 4.2-3-8 1 for Sail Pro (with Alternater)
6 Screw 1 for Sail Pro (with Alternater) M4 L=8mm
7 Washer 1 M12
8 Nut 12-P1.25 1
9 Igniter W/Resistance Cap 1
10 Plug Cap W/Resistance 1
11 Bolt 2 M6 L=30mm
12-1 Clamp 6.5-67P 2
12-2 Clamp 6.5-47.5P 1
13 Screw 1 M6 L=12mm
14 Rectifier Complete 1 for Sail Pro or OPT
15 Fuse (10A) 1
16 Battery Cable L=494 1 with Alternator Sail Pro Only
17 Cable Terminal Plug 1 with Alternator Sail Pro Only
18 Grommet 17-3 1
19 Pilot Lamp Ass'y 1
20 Stop Switch Ass'y 1
21 Stop Switch Lanyard Ass'y (W/Curl) 1
22 Clamp 6.5-14 1
23 Bolt W/Washer 1 M6 L=12mm
24 Clamp 6.5-14 1 Sail Pro
25 Bolt W/Washer 1 Sail Pro M6 L=12mm
26 Protector Wire Harness 1
27 Electric Bracket Ass'y 1 Sail Pro
28 Clamp 6.5-14 1 Sail Pro
29 Bolt 4 Sail Pro M6 L=14mm
30 Band Lead Wire 135 1 Sail Pro
Ref.
No.
Description RemarksQ'ty
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ21
