TOHATSU MFS 4C Service Manual

11-23
4st 4/5/6 2011
11
1-1 Drive Shaft Housing Ass'y (S) 1 for Transom “S”
1-2 Drive Shaft Housing Ass'y (L) 1 for Transom “L” Use 369-60003-0
1-3 Drive Shaft Housing Ass'y (L) 1 for Transom “UL” Use 3AB-60003-0
2 Bushing Shift Lever 1
3-1 Drive Shaft Bushing Ass'y 1 for Transom “L”
3-2 Drive Shaft Bushing Ass'y 1 for Transom “UL”
4-1 Drive Shaft Bushing (Slate Color) 1 for Transom “L”
4-2 Drive Shaft Bushing (Dark Brown) 1 for Transom “UL”
5 Stopper Drive Shaft 1
6 Screw Pre coated 5-25 2 for Transom “L/UL”
7Washer 2 M5
8 Screw 2 for Transom “S” M5 L=10m
9 Grommet Cam Rod 1
10 Dowel Pin 6-12 2
11 Bolt 1 M8 L=8mm
12 Gasket 8.1-15-1 1
13 Grommet 29.3 1
14 Bolt 6 M6 L=30mm
15 Drive Shaft Housing Gasket 1
16 Extension Housing 1 for Transom “UL”
17 Bolt 1 for Transom “UL” M6 L=25mm
18 Washer 1 for Transom “UL” M6
19 Stud Bolt 1 for Transom “UL” M8 L=25mm
20 Washer 1 for Transom “UL” M8
21 Nut 1 for Transom “UL” M8
22-1 Shift Rod (S) 1 for Transom “S”
22-2 Shift Rod (L) 1 for Transom “L”
23 Shift Rod Lever 1
24 Pin Shift Lever 1
25 Split Pin 1
26 Shift Rod Joint Ass'y 1
27 Washer 1 M6
28 Bolt 5-16 1 M6 L=16mm
29 Bolt 1 M4 L=16mm
30 Shift Lever Shaft Ass'y 1
31 O-Ring 1.9-8.8 2
32 Ceramic Ball 7.7 1
33 Spring Shift Lever Stopper 1
34 Shift Lever Rod 1
35 Pin Shift Rod Lever 1
36 Snap Pin 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ23
