TOHATSU MFS 4C Service Manual

11-25
4st 4/5/6 2011
11
1 Swivel Bracket A 1
2 Swivel Bracket B 1
3 Clamp Bracket (R) 1 Stern Bracket Right Starboard Side
4 Clamp Screw Kit 2
5 Clamp Screw 1
6 Clamp Screw Handle 1
7 Rivet 3-22 1
8 Clamp Screw Pad 1
9 Shoulder Bolt 1
10 Clamp Bracket (L) 1 Stern Bracket Left Port Side
11 Bolt 8-122 1
12 Nylon Nut 8P1.25 1 M8
13 Washer 1 M8
14 Washer 8.5-28-1 2
15 Distance Plate Bracket 1
16 Screw 2 M6 L=12mm
17 Stern Bracket Spring 1
18 Screw 1 M4 L=6mm
19 Washer 4.3-16-1.5 1
20 Thrust Rod 1
21 Thrust Rod Spring 1
22 Bolt 4 M6 L=40mm
23 Thrust Bushing 1
24 Bushing Upper Steering 1
25 Bushing Lower Steering 1
26 Friction Band Ass'y 1
27 Thrust Plate (Lower) 2
28 Spring Co-pilot 1
29 Wing Nut M6 1
30 Washer 6-16-1.5 1
31 Tilt Stopper Ass'y 1
32 Tilt Stopper Grip 1
33 Bushing Tilt Stopper 2
34 Setting Plate Tilt Stopper 1
35 Bolt 2 M6 L=12mm
36 Grease Fitting 2
37 Reverse Lock Arm 1
38 Bolt 2 M6 L=14mm
39 Reverse Lock Spring (R) 1
40 Reverse Lock Spring (L) 1
Ref.
No.
Description RemarksQ'ty
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ25
