TOHATSU MFS 4C Service Manual

11-27
4st 4/5/6 2011
11
1 Bottom Cowl 1
2 Grommet ø5.5-ø9.5-44 1
3 Cowl Latch Ass'y 1
4 Bolt 1 M6 L=16mm
5 Grommet ø10.5-ø15.5-ø20.5-32 1
6 Grommet 18-2.5 1
7 Grommet 25-5 1 Dual Fuel Tank
8 Grommet 17-2.7 1
9 Plastic Rivet 6.5 1
10 Fuel Connector (Engine Male) 1
11 Protector Fuel Connector 1
12 Bolt 1 M6 L=25mm
13 Washer 1 M6
14 Fuel Hose W/Protector 1 USA/Separate Fuel Tank
15 Fuel Hose 1 STD/Separate Fuel Tank
16 Clip 2 Separate Fuel Tank
17 Fuel Cock Ass'y 1 Dual Fuel Tank
18 Screw 2 Dual Fuel Tank
19 Grommet 1 Separate Fuel Tank
20 Choke Rod 1
21 Choke Rod Bushing 1
22 Grommet 21-38.5 1
23 Shift Lever 1
24 Collar 15.9-17.9 1
25 Washer 30-45-1 1
26 Bolt 1
27 Washer 6.5-23-1.5 2
28 Cable Terminal Plug 1
29 Storage Decal 1
30 Oil Pressure Decal 1
31 Spark Plug Decal 1
32 Fuel Lever Decal 1
33 Bolt 2 M6 L=12mm
34 Washer 6.5-23-1.5 2
35 Bolt 1 Separate Fuel Tank STD M6 L=12mm
36 Washer 6.5-23-1.5 1 Separate Fuel Tank STD
37 Bolt 4 M6 L=16mm
38 Tiller Handle Ass'y 1
39 Tiller Handle 1
40 Plastic Rivet 6.5 1
41 Grip 1
42 Throttle Shaft 1
43 Throttle Shaft Damper 1
44 Bushing 14-15.8-7 1
45 Screw 1 M5 L=18mm
46 Screw 1 M6 L=12mm
47 Throttle Shaft Supporter 1
48 Friction Piece 1
49 Adjusting Nut 1
50 Tiler Handle Spring 1
51 Bolt 1 M6 L=25mm
52 Throttle Decal 1
53 Spacer ø33.5-ø55 1
54 Washer 30-45-1 1
55 Throttle Wire 2
56 Protector 1
57 Bushing Steering 2
58 Cover 1
59 Bolt 2 M6 L=16mm
60 Shift Decal 1
Ref.
No.
Description RemarksQ'ty
MFS4-5-6Ech11110425.qxd11.4.2511:21AM  ページ27
