TOHATSU MFS 4C Service Manual

2-16
Service Data
4st 4/5/6 2011
O ring (shift lever)
Shift lever
Taper plug 1/8
Drive shaft (spline)
Ball bearing
Needle bearing inner
Bolt (gear case)
Oil seal (pump case lower)
Pump case liner
Cam rod bushing
O ring (cam rod bushing)
Bolt (cam rod bushing)
Bolt (cam rod bushing)
Ball bearing
Needle bearing
Propeller shaft housing
Bolt (propeller shaft housing)
O ring
Oil seal
Propeller shaft
Ball bearing
Stern bracket plate
Clamp screw
Swivel bracket (bracket bolt)
Swivel bracket (tilt stopper mount)
Steering bush
Thrust plate
Tiller handle
Throttle burden
Bushing (tiller handle)
Throttle shaft
Throttle wire
Choke rod grommet
Bush (hook lever)
Seal ring (hook lever)
Starter seal rubber
Nipples
Amount of engine oil
Gear oil
Lower unit
Shift
Drive shaft
housing
Drive
shaft
Gear case
Propeller
shaft
housing
Cowl
Sliding surface
Thread
Crankshaft spline
at press fitting
at press fitting
Thread
Lip
Outer surface, at press fitting
Impeller sliding surface
Thread
Thread
at press fitting
at press fitting
inlow
Thread
Lip
Outer surface, at press fitting
Spline
at press fitting
Washer, 8.5-28-1.0
Thread
Sliding surface
Sliding surface
all area
all area
Grip sliding face
Inner
Inner and outer surfaces
Sliding face (except slide adjusting section)
Wire
Inner
Inner and outer surfaces
Lip
Press fit section
450ml when replaced
Oil capacity 195ml
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
Bracket
Tiller
handle
Screw locking agent Adhesive Cold resistant lithium grease LIT Water resistant grease OBM Rubber grease RUB Teflon grease TEF Silicone grease SOC 4 stroke engine oil Tohatsu genuine gear oil
Konishi
1342 G17 G103 1741 2000
FM-
531
Bentax
2
LM-
902
KS-
64
Centax
L2
Liquid
O-Ring
Shin-Etsu
Chemical
Chuoh Yuka
Apply to
Remarks
Instantaneous adhesive Sealing agent
Three
Bond
Three
Bond
