TOHATSU MFS 4C Service Manual

4
4-5
4st 4/5/6 2011
1 Intake Manifold Ass'y 1
2 Intake Manifold Gasket 1
3-1 Bolt 1 Dual Tank Mode M6 L=25mm
3-2 Bolt 2 Separate Tank Model M6 L=25mm
3-3 Bolt 1 Dual Tank Mode M6 L=30mm
4-1 Carburetor Ass'y 1 5ps
4-2 Carburetor Ass'y 1 4ps
4-3 Carburetor Ass'y 1 6ps
4-4 Carburetor Ass'y 1 5ps for EU
4-5 Carburetor Ass'y 1 4ps for EU
4-6 Carburetor Ass'y 1 6ps for EU
5-1 Main Nozzle 1 5ps
5-2 Main Nozzle 1 4ps
5-3 Main Nozzle 1 6ps
5-4 Main Nozzle 1 5ps for EU
5-5 Main Nozzle 1 4ps for EU
5-6 Main Nozzle 1 6ps for EU
6-1 Main Jet (#65) 1 5ps
6-2 Main Jet (#60) 1 4ps
6-3 Main Jet (#58) 1 4ps for EU
6-4 Main Jet (#68) 1 6ps
7-1 Slow Jet (#38) 1 5/6ps
7-2 Slow Jet (#35) 1 4ps
8 Float 1
9 Float Valve 1
10 Clip 1
11 Float Arm Pin 1
12 Float Chamber 1
13 Float Chamber O-Ring 1
14 Screw 2 M4 L=12mm
15 Drain Screw 1
16 O-Ring Drain Screw 1
17 Stop Screw 1
18 Spring Stop Screw 1
19-1 Pilot Screw 1
19-2 Pilot Screw (EU) 1 for EU
20 Carburetor Gasket 2
21 Insulator 1
22 Intake Silencer 1
23 Flame Arreste 1
24 Collar 6.2-9-7.4 2
25 Collar 6.2-9-7 1
26 Bolt 2 M6 L=85mm
27 Washer 2
28 Cable Holder 1
29 Bolt 1 M6 L=16mm
30 Nut 1 M6
31 Fuel Pump Ass'y 1
32 Check Valve P 1
33 Check Valve 1
34 Pump Body Gasket 1
35 Pump Diaphragm 1
36 Screw 2 M3 L=8mm
37 Screw 4 M4 L=18mm
38 O-Ring 2.62-18.72 1
39 Screw 2 M6 L=30mm
40 Choke Wire 1
41 Washer 6.5-21-1 1
42 Bolt 6-12 1 M6 L=12mm
43 Fuel Hose 4.5L-115 1
44 Clip Fuel pipe 5
45 Fuel Filter Ass'y 1
46 Hose 1 98AB-501000
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
MFS4-5-6Ech04110422.qxd 11.4.22 5:48 PM  ページ5
