TOHATSU MFS 4C Service Manual

4
4-15
4st 4/5/6 2011
5. Disconnect breather hose 5 from intake silencer.
55
6. Remove fuel hose 6 from fuel pump.
66
7. Loosen carburetor mounting bolts and remove carburetor
7.
When removing throttle rod and carburetor, perform the
work as shown taking care not to give damage to the
parts.
77
Before disconnecting fuel hose, place a piece of
cloth below fuel pump to blot leaking fuel.
44
4. Remove recoil starter ass'y 4.
Since throttle rod is bent at the tip, remove
carburetor by inclining and pulling it as shown.
MFS4-5-6Ech04110422.qxd 11.4.22 5:48 PM  ページ15
