Tonghui TH9310 Series - Setup

◇24
5. The system will start upgrading automatically. It will reboot automatically after
finishing upgrading.
6. Enter into the lock system keyboard(F5) and input the system lock password. The
default password is 9310.
7. Log-in the system interface and enter into the system password item.
8. Set the system password function as OFF and input the password. The password is
9310.
4.2.1 SETUP
MEAS SETUP
INS
F1
STEP:
01/01
FUNC
AC
VOLT:
0.050
kV
UPPR:
1.000
mA
DEL
F2
TIME:
0.5
S
LOWR:
OFF
RISE:
0.5
S
ARC:
OFF
NEW
F3
FALL:
0.5
S
FREQ:
50
Hz
UP
F4
DOWN
F5
Message
Figure 4.2.1 AC setup interface
Modification Instruction of the test programme
STEP: 01/01 Test procedure: current setting No. / total items.
Item identification of the test programme, current test programme No./ total items
Key
Function
Instruction
F1
INS
Add a new test item. The current item and subsequent items will
move one step backward.
F2
DEL
Delete the current test item. The subsequent item will move one
step forward.
F3
NEW
Create a blank test programme (PROG). The system will
automatically create a default test item. Please remember to save
the test programme after finishing writing.
F4
+
Visit the parameter of the step after the current displayed step.
F5
-
Visit the parameter of the step before the current displayed step.
AC Current operating mode of test procedure is AC withstanding voltage.
The current working mode of the test item is AC withstanding voltage. Cursor in this position can switch to
other working items by F1~F4, for instance DC, IR and OS. For details of parameter modification of
the test item, see 4.3 test item interface and parameter setup.
NOTE:
For ease of use, press the ‘START’ key on this interface to enter into the test interface directly and
simultaneously start testing according to the current set test programme.
If fault triggering of ‘START’ occurs, pull out of the INTLOCK jumper before changing the
parameter to avoid danger.
