4.2.2 TEST (Take AC for example)
MEAS SETUP
MEAS
SETUP
F1
STEP:
01/01
FUNC
AC
VOLT:
0.050
kV
UPPR:
1.000
mA
SYSTEM
SETUP
F2
TIME:
0.5
S
LOWR:
OFF
V：
0 . 0 0 0
Kv~
FILE
SETUP
F3
I：
0 . 0 0 0
mA
F4
T:
0 . 0
S
F5
Message
Figure 4.2.2 AC test interface
Note：
1. The high voltage can only be started on this interface to test high voltage. Other test conditions
have to been set on setup interface.
2. Press  to enter the SETUP interface.
3. The function key F5 can lock the keyboard. When the keyboard is locked, only three keys:
START, STOP and F5 (unlock）are usable. Otherwise, the unlocking operation is also
controlled by the PASSWORD function in the SYSTEM interface.
The three large font data in the middle of the front panel is the real time test data. After finishing
testing, the last test result will be displayed on the panel before pressing the STOP key.
The top one is high voltage output voltage, the unit is (kV).
The middle one is the tested current of low terminal, the unit is (mA) and (uA).
The bottom one is the remained time in testing high voltage. If operator turns off the time control,
the test time no less than 999.9S will be displayed. user can analyze the test condition of DUT with the
unit of (S).
！Note：
Operator can not leave the test position if the tester is working;
In the process of testing, do not close to the test line or DUT.
4.2.3 SYSTEM
System interface is to set the test programme of the instrument, not the specific test component
parameters.
