Tonghui TH9310 Series - 4.3 Test item interface and parameter setup

◇29
Operation interface of the external file:
<EXTERNAL FILE>
Load
F1
STA
2011/ 11/11
11 ：11
Save
F2
FILE-A1.STA
2012/ 05/ 20
13 ：14
Delect
F3
FILE-A2.STA
2013/09/19
19 ：09
Copy To
I:
F4
FILE-A3.STA
2099/ 09/ 09
09 ：09
Select
F5
PAGE 1
4.2.4.3 Operation interface of the external file:
4.3 Test item interface and parameter setup
This section describes each test function parameter and its definition of the setup interface to help the
customer set the revelant parameters.
4.3.1 AC withstanding voltage test parameter setup：
MEAS SETUP
AC
F1
STEP:
01/01
FUNC
AC
VOLT:
0.050
kV
UPPR:
1.000
mA
DC
F2
TIME:
0.5
S
LOWR:
OFF
RISE:
0.5
S
ARC:
OFF
IR
F3
FALL:
0.5
S
FREQ:
50
Hz
OS
F4
F5
Message
Figure 4.3.1 AC setup interface
Instruction:
VOLT
0.050~5.000kV
Voltage value of AC high voltage test
UPPER
0.001~20.00mA
Current upper limit value of AC
withstanding voltage (TH9320 series)
0.001~10.00mA
Current upper limit value of AC
withstanding voltage (TH9310 series)
LOWR
0.001~20.00mA
Low limit current value of AC, it must be
smaller than the upper limit value
(TH9320 series)
0.001~10.00mA
Low limit current value of AC, it must be
smaller than the upper limit value
(TH9310 series)
OFF
No requirement for the low limit value
ARC
0.1~20.0 mA
Current Max. value of AC arc
