◇59
4. Edit the interface switching instruction (DISP: PAGE <NAME>), and see if the instrument interface
switching is normal.
5. DISP：PAGE_SYST (NL^END) To enter the system interface. (SYST commands)
6. SYST：FAIL _1 (NL^END) To set system parameters.
7. DISP：PAGE_MSET (NL^END) To enter the setup interface. (FUNC commands)
8. FUNC：SOUR：STEP_NEW (NL^END) To edit a new test file
9. FUNC：SOUR：STEP_1：AC：VOLT_1000;UPPC_1;TTIM_9.9; CH1_HIGH; CH2_LOW (NL^END)
Add the parameters of Step 1
10. FUNC：SOUR：STEP_INS (NL^END) Create a new step.
11. FUNC：SOUR：STEP_2：DC：VOLT_1000; UPPC_1; TTIM_9.9; CH1_HIGH; CH2_LOW
(NL^END) Add the parameters of step 2.
12. You can repeat step10-11and up to 20 STEPs can be added.
13. In the setup interface (MSET) or test (MEAS) interface, use FUNC:STAR
Note: In the example, "_" is a space mark, and (NL^END) is an end mark.
