Topcon A3524 User Manual

5-1
A3524 Rev 1.1
Installing Topcon Hiper-AG RTK Mobile Base Station
Installing Topcon Hiper-
AG RTK Mobile Base
Station
The Hiper-AG RTK Base Station can be used in two different
congurations; either as a low-power mobile RTK Base Station or as a
high-power permanently xed RTK Base Station (see Chapter 6).
Required Components
Hiper-AG GPS receiver•
Power cable•
Comms cable•
UHF Portable antenna•
Mounting tripod•
Connecting the Power/ Communication cables
The two serial ports (Figure 5-1) can both be used to communicate with
the X20 console.
When the External Power Port (Figure 5-1) is connected to the 12V
battery (via the red-shrouded ODU cable) it provides the Hiper-AG’s
internal battery with power.
