6-5
A3524 Rev 1.1
Installing Topcon Hiper-AG RTK Fixed Base Station
Power Connection
A power cable is supplied fo the Hiper-AG unit.
The power leads are tted with 3 amp automotive blade fuses.
The power cables are tted with ½” (12mm) insulated ring terminals for
connection to a (user-supplied) battery or other voltage-regulated power
source. The recommended battery size is 50 amp/hour and should be a
deep cycle type for mobile installations.
Do not change the 3 amp automotive blade fuses
to a higher rating as damage to the radio and/or
GPS could result.
Do not power the Hiper-AG unit until the external
antenna has been connected.
CAUTION
CAUTION
