SETTING
[display]
D.A.N
NO.
OPTIONS [displayed]
BOLD=DEFAULT
DESCRIPTION
OPSTAT PORT
5007
OFF, COM1, COM2,
COM3
Sets opstat port
DDL PORT
5009
OFF, COM1, COM2,
COM3
Sets DDL port
20MA MIRROR
PORT
5011
OFF, COM1, COM2,
COM3
Sets port for 20MA signal to mirror
RECIPE PORT
5012
OFF, COM1, COM2,
COM3 invalid
Sets recipe output port
DEBUG PORT
5999
OFF, COM1, COM2,
COM3
Sets debugger port
SETUP FEATURES
SIGNON
SETTING
8001 OFF,ON Enables continuous display of sign-on message
SIGNON
MESSAGE
8002 SIGMSG 1,2,3 Enables editing of the sign-on message
MAINTENANCE
MESSAGE
8011
MANTMG 1, 2, 3, 4, 5, 6,
7, 8, 9, 10, 11
Enables editing of the maintenance message
MAINTENANCE
MESS. TIME
8012
Time is entered using key
pad.
Time for maintenance message to be triggered.
DEAD WEIGHT
CAL
8121
Follow instructions shown
on LCD
Calibration method using weights
TEMPERATURE
CALIBRATION 8123 OFF/ON
On=Scale adjusts for temperature changes
INDICATOR
SETUP INFO
8299 Downloads all setup information to the serial port
KEYTEST 8888 Enables front panel key test
SETUP & CALIBRATION
SETUP NUMBER
8711 146040
Quick entry method selects weigh method 1-4 lbs, 5-8 kg, gain 1-9,
display counts 1-9 and capacity *1000
Calibration
Number
8712 32640 Weight displayed at 0.4mV/V
