1 NOMENCLATURE AND FUNCTIONS
1 NOMENCLATURE AND FUNCTIONS
1.1 Nomenclature
Point guide
Objective lens, Tele sensor
Display window
(With touch panel)
Instrument
center mark
Optical plummet
telescope
Operation keys
Leveling screw
Base
Handle fixing screw
Sighting collimator
Carrying handle
Power supply
connector
(Serial signal connector RS-232C)
Communication port
Stylus pen
GPT-7001i
GPT-7002i
GPT-7003i
GPT-7001i/7002i/7003i
GPT-7001i/7002i/7003i
Laser pointer
Laser aperture
Wide sensor
