1-2

1 NOMENCLATURE AND FUNCTIONS

*The position of vertical motion clamp and Vertical tangent screw will differ depending on the market.

Horizontal

tangent screw

Battery locking lever

On-board battery

BT-52QA

Instrument

center mark

Horizontal

motion clamp

Power supply

connector

Serial Signal

connector

Display unit

Plate level

* Vertical tangent screw

* Vertical motion clamp

Telescope eyepiece

Telescope grip

Telescope focusing knob

Sighting collimator
