6 SPECIAL MODE (Menu Mode)
6.6.6 Setout Road
To setout the road, carry out the following operating procedure.
Operating procedure Operation Display
1 After pressing the [MENU] key, press the [F4](P
↓
),
[F1], [F4] key to get the programs menu on page
2/2.
[MENU]
[F4]
[F1]
[F4]
2 Press the [F3], [F2], [F2] key.
(Refer to “Set out road” on page 24.)
[F3]
[F2]
[F2]
3 Input data.
Input
data
4 Press the [ENT] key.
[ENT]
5 Select offset.
(Example: RIGHT)
Press the [F2] key. *1)
[F2]
6 Input the offset value.
7 Press the [ENT] key.
The setout point coordinates are displayed.
Input
offset value
[ENT]
8 Press the [F3](YES) key.
The distance to the setout point and the backsight
are displayed.
HR: Calculated horizontal angle of the layout point
HD: Calculated horizontal distance from the
instrument to the layout point
[F3]
9 Press the [F1](ANG) key.
CHAIN: Layout point
HR: Measured (Actual) horizontal angle.
dHR: Horizontal angle to be turned to the layout
point = Actual horizontal angle - Calculated
horizontal angle.
Correct direction when dHR = 0°00'00"
[F1]
10 Press the [F1](DIST) key.
HD: Measuring (Actual) horizontal distance
dHD: Horizontal distance to be turned to the
layout point = Actual horizontal distance –
Calculated horizontal distance.
[F1]
PROGRAMS 2/2
F1:AREA
F2:POINT TO LINE
F3:ROAD P
↓
SETOUT ROAD
CHAIN=
--- --- [CLR][ENT]
SETOUT ROAD
CHAIN=1200
--- --- [CLR][ENT]
CHAIN:1200
> CENTER
LEFT RIGHT --- ENTER
CHAIN:1200
: RIGHT
= m
--- --- [CLR][ENT]
CHAIN:1200
N : 0.000 m
E : 0.000 m
>OK ? [YES][NO]
CALCULATED
HR= 60°00’00”
HD= 100.000 m
ANG DIST --- ---
CHAIN:1200
HR: 60°00’00”
dHR: 0°00’00”
DIST --- NEZ ---
HD* 100.000 m
dHD: 0.000 m
MODE ANG NEZ NEXT
