Topcon GTS-239N - Input Start Point

6-25
6 SPECIAL MODE (Menu Mode)
6.6.1 Input Start Point
To input the start point, carry out the following operating procedure.
Operating procedure Operation Display
1 After pressing the [MENU] key, press the [F4](P ↓ ),
[F1], [F4]key to get the programs menu on page
2/2.
[MENU]
[F4]
[F1]
[F4]
2 Press the [F3], [F1], [F1] key.
(Refer to “Input start point” on page 24.)
[F3]
[F1]
[F1]
3 Input coord N, E.
4 Press the [ENT] key.
Input coord
[ENT]
5 Input value data CHAIN, INTERVAL.
6 Press the [ENT] key.
Input data
[ENT]
z For [ROAD], in addition to the “Start Point” and “Road Data” input files, other files necessary for the
calculations are created. Consequently, if the free area of the memory reaches 10% or less, a
“MEMORY POOR” warning message is displayed. (In this case, the instrument can still be operated.)
z CHAIN and INTERVAL input range
-50,000m≤ CHAIN ≤ +500,000m
0m<INTERVAL ≤ +5,000m
PROGRAMS 2/2
F1:AREA
F2:POINT TO LINE
F3:ROAD P
↓
START POINT
N = 0.000 m
E : 0.000 m
––– ––– [CLR][ENT]
START POINT
CHAIN = 0.000 m
INTERVAL:100.000 m
––– ––– [CLR][ENT]
<SET!>
INPUT DATA
F1:START POINT
F2:H ALIGNMENT
