22-1
22 ERROR DISPLAYS
22 ERROR DISPLAYS
Error code Description Countermeasures
3 points
required
When area calculating, there are less than 3
points coordinate data in selected file.
Confirm the file data and calculate again.
CALC
ERROR
Calculation is impossible from the data input. Confirm the input data.
DELETE
ERROR
When deleting coordinate data, it can not
be done successful.
Confirm the data and delete again.
E35
Displayed when REM measurement carried
out to the range from zenith or nadir ±6°.
Operate in the range out of ± 6° from the
zenith or nadir.
E60’s
Any abnormality occurs with EDM (distance
measuring system).
Repair is required.
E71
Displayed when vertical angle 0 position is
set with incorrect procedure.
Confirm the procedure and readjust.
E72
Displayed when Vertical angle -position is
adjusted in wrong position.
Repair is required.
E73
The instrument was not leveled when Vertical
angle 0-position is adjusted.
Level the instrument then carry the
adjustment work.
E80’s
Mainly at the time data transmission between
GTS-230N series and external instrument.
Confirm operation procedure is correct or the
connection cables are correct.
E90’s Abnormality in internal memory system. Repair is required.
FILE
EXISTS
The same file name exists. Use another file name.
FULL
FILES
When making a file, 30 files already exist. If necessary, send or delete files.
FAILED
INITIALIZE
Initializing can not be done successful. Confirm initializing data and try to initialize
again.
LIMIT
OVER
Limit of input data exceeded. Input again.
MEMORY
ERROR
Any abnormality occurs with internal memory. Initialize the internal memory.
MEMORY
POOR
Shortage of capacity of the internal memory. Download data from internal memoryto PC.
NO DATA The data is not found in the search mode Confirm the data and search again.
NO FILE There is no file in internal memory. If necessary, make files.
FILE NOT
SELECTED
When using a file, no file is selected. Confirm the file and select a file.
P1-P2
distance
too short
When in point to line measurement, the
horizontal distance between first point and
second point is within 1m.
The horizontal distance between first point
and second point must be more than 1m.
CIRCULAR
ERROR
Known points and occupied point are on the
same circle at the resection mode.
Take the different point.
PT# EXIST
Same new point name is already memorized
in the memory.
Confirm the new point name and input again.
To Next Page
