4-9
4 DISTANCE MEASUREMENT
6 Collimate prism P, and press the [F1](MEAS) key.
Measuring will start.
Collimate P
[F1]
After measuring, the result added offset value will
be shown.
7 Show the relative elevation of point P0.
z Each time pressing the [ ] key, horizontal
distance, relative elevation and slope distance are
shown in sequence.
[]
z Show coordinate of point P0.
[]
z To return to procedure
4, press [F1](NEXT) key.
z To return to the previous mode, press [ESC] key.
DISTANCE OFFSET
HR: 80°30'40"
HD* [n] << m
>Measuring...
DISTANCE OFFSET
HR: 80°30'40"
HD* 10.000 m
NEXT --- --- ---
DISTANCE OFFSET
HR: 80°30'40"
VD: 11.789 m
NEXT --- --- ---
DISTANCE OFFSET
HR: 80°30'40"
SD: 11.789 m
NEXT --- --- ---
N : 12.345 m
E : 23.345 m
Z : 1.345 m
NEXT --- --- ---
