PREPARATIONS
SETTING RS232C COMMUNICATION SPEED
The RS232C communication speed can be set. Before shipment, it is set to “2400” (baud rate
2400).
1 In the “INITIAL MENU SCREEN”, choose “ON-LINE” and get the “ON-LINE SCREEN”.
2 Press the and move the cursor to “BAUD-RATE”.
3 Press the and choose:
2400 (baud rate 2400), or
9600 (baud rate 9600).
4 Press the ,and the cursor moves to the next item.
SELECTING RS232C OUTPUT DATA (Only in KR-8800)
1 Press the and bring the cursor to “OUTPUT DATA TYPE”s.
2 Press the and choose
REF (data of refractometer only),
KRT (data of keratometer only), or
ALL (data of both refractometer and keratometer).
3 Press the ,and the cursor moves to the next item.
For inquiries about the RS232C communication format, please contact your dealer
or Topcon at the address stated on the back cover.
MEASURE SWITCH ITEM
PRINT SWITCH SELECT
CL INPUT
DATA FORMAT
BAUD-RATE
OUTPUT DATA TYPE
EXIT
ON-LINE
2400
9600
MEASUREMENT SWITCH
PRINT SWITCH
MEASUREMENT SWITCH
MEASUREMENT SWITCH
MEASURE SWITCH ITEM
PRINT SWITCH SELECT
CL INPUT
DATA FORMAT
BAUD-RATE
OUTPUT DATA TYPE
EXIT
ON-LINE
REF
KRT
ALL
PRINT SWITCH
MEASUREMENT SWITCH
