PREPARATIONS
SETTING STEP
The measurement step can be selected from 0.12, 0.25. Before shipment, it is set to “0.25”.
1 Press the of the control panel and get the “SETTING MENU SCREEN”.
“STEP” is inverted, and measurement steps are displayed on the right with the set step
inverted.
2 Press the and invert the desired measurement step.
3 Press the ,and the cursor moves to the next item(AXIS STEP).
SETTING AXIS STEP
The axial angle step can be selected from 1 and 5. Before shipment, it is set to “1”.
1 Press the of the control panel and get the “SETTING MENU SCREEN”.
2 Press the and invert “AXIS STEP”.
“AXIS figures” are displayed on the right.
3 Press the and invert the desired “AXIS” figure.
4 Press the ,and the cursor moves to the next item(VD) .
MENU SWITCH
PRINT SWITCH
MEASURE SWITCH ITEM
PRINT SWITCH SELECT
STEP
AXIS STEP
VD
CONT.MEAS.
OUTPUT DATA
SETTING MENU
0.12
0.25
MEASUREMENT SWITCH
MENU SWITCH
MEASUREMENT SWITCH
PRINT SWITCH
MEASURE SWITCH ITEM
PRINT SWITCH SELECT
STEP
AXIS STEP
VD
CONT.MEAS.
OUTPUT DATA
SETTING MENU
1
5
MEASUREMENT SWITCH
