2 L a s e r C a r M o d e.
1 T a b l e M o d e.
3 E q u i p m e n t T y p e.
4 B u z z e r S e t t i n g.
ESCSave
1
2014 03 10 11 00- - :
General
Common
Single
Fig. 5-16
Press the ―Up/Down‖ key to select the needed operation. Click on the ―Choose‖ key to
change setting, ―Number‖ keys to set the value.
Table model: General or Double. After choosing double table model, and set the
Table Size parameter–the distance of double table model, the distance subjects to
the two upper left corner of table model. The machine on double table has two
tables: to go back and forth by Z axis, keep a table on the working position; and
another one turn in there on the both sides of machine.
LaserCar Mode: Single, Double1, Double2. Single means it just has one laser
head. Double1 means it has two laser heads on one belt. Double2 means it has
two laser heads with two belts. After choosing Double1 or Double2, need to set the
Double Head Intv. parameter—which is the origin points between the two laser
head. The X axis and V axis are used to control the two laser head movement. The
X axis control the laser head near the origin of the machine, V axis control the laser
head away from the origin of the machine. The X axis range is set to the maximum
width of the machine can be processed. V axis range is set to X axis range minus
the distance between two laser head. When it’s even column, the two head will
work at the same time; when it’s odd column, one head on the last column work.
Equipment Type: Common, Round (machine with wheel).
a. When choose the wheel device, need to set the parameters: Reference
Diameter and Reference Resolution.
Reference Resolution instructions:
a. Menu/Integrate/Equipment: Set the Equipment to Round. The ―Reference
Diameter‖ and ―Reference Resolution‖ are used to calculate the actual
resolution with the different cylindrical materials.
b. Reference Parameters
