Fig. 5-22
Init Back: Set which axis goes back to origin after power up.
Manual Back: Manually set single axis back to origin.
In initialization back operation interface, press ―Up/Down‖ key to select the needed
operation, ―Choose‖ key to change setting. If the parameter set to Open, the axis
automatically move back to origin after machine power up, and the coordinate will back
to zero. If close, the axis moves none, and the stop position will be the origin of axis.
Press ―Enter‖ to save configuration, ―ESC‖ to quit.
Open
Back Operate
2. Y B a c k t o O r i g i n
1 X B a c k t o O r i g i n.
3. Z B a c k t o O r i g i n
4. U B a c k t o O r i g i n
5. V B a c k t o O r i g i n
ESCSave
Open
Close
Close
Close
2014 03 10 11 00- - :
Fig. 5-23
In Manual Back interface, Press the ―Up/Down‖ key to select the needed operation.
Click on the ―Enter‖ to set one axis back to origin.
