Understanding the InfoCenter Menu Items
T o access the main menu, press any button while at
the main, CU motor , or traction information screen,
then press the button that corresponds with the
symbol. This brings you to the M AIN M ENU .
Refer to the following tables for a description of the
options available from the menus:
Main Menu
Menu Item Description
F AULTS The F AULTS menu contains
a list of the recent machine
faults. Refer to the Service
Manual or your authorized
T oro distributor for more
information on the F AULTS
menu.
S ERVICE The S ERVICE menu contains
information on the machine
such as hours of use, counts,
and calibration. Y ou can
also enable the cutting-unit
backlap procedure. Refer to
the Service ( page 21 ) table.
D IAGNOSTICS The D IAGNOSTICS menu lists
various states and data that
the machine currently has.
Y ou can use this information
to troubleshoot certain issues,
as it quickly tells you which
machine controls are on/of f
and lists control levels (e.g.,
sensor values).
S ETTINGS The S ETTINGS menu allows
you to customize and modify
conguration variables on the
InfoCenter display . Refer to
the Settings ( page 21 ) table.
A BOUT The A BOUT menu lists the
model number , serial number ,
and software version of your
machine. Refer to the About
( page 22 ) table.
Faults
Menu Item Description
C URRENT Lists the total number of
key-on hours (i.e., hours that
the key has been in the O N
position).
L AST Indicates the last key-on hour
that the fault occurred on.
F IRST
Indicates the rst key-on hour
that the fault occurred on.
O CCURRENCES Indicates the number of fault
occurrences.
Service
Menu Item Description
H OURS
Lists the total number of
hours that the key , reels, and
backlap have been on.
C OUNTS Lists the number of mows,
tap-of fs, and backlaps.
B ACKLAP
Engages/disengages the
cutting-unit backlap procedure
(when you engage this
procedure, you can disengage
the mode with this setting or
by moving the key to the O FF
position).
C ALIBRATION
Allows you to calibrate the
steering system, traction
system, and lift actuators.
Refer to the Service Manual
for more information on
calibration.
Settings
Menu Item Description
U NITS
Controls the units used on the
InfoCenter . The menu choices
are English or metric.
L ANGUAGE
Controls the language used
on the InfoCenter .
B ACKLIGHT
Controls the brightness of the
LCD display .
C ONTRAST Controls the contrast of the
LCD display .
P ROTECTED M ENUS Allows you to access
protected menus by inputting
a passcode.
P ROTECT S ETTINGS
Controls the protected menus.
R ESET D EFAULTS
Resets the InfoCenter to
default settings.
T APOFF T IME
Controls the tap-of f delay .
R EEL S PEED
Controls the reel speed.
L OWER S PEED
Sets the speed that the cutting
units lower to the ground for
mowing.
B ACKLAP RPM
Controls the backlap rpm
speed.
C LIP C ONTROL
T urns the automatic
clip-control feature O N /O FF .
B LADE C OUNT
Set the number of blades in
each reel. This setting is only
necessary if C LIP C ONTROL is
set to O N .
H EIGHT OF C UT (HOC)
Sets the desired height of cut.
This setting is only necessary
if C LIP C ONTROL is set to O N .
21
