DriveWheelReleaseValves
Thedrivewheelreleasevalvesarelocatedontheleftandright
sidesunderneaththefrontoftheunit.
Note:Duringnormaloperatingconditions,thewasheron
theleverispositionedinsidetheslots.
Ifyouneedtopushthemachinebyhand,makesurethatthe
valvesareinthe“released”position(Figure11).
Figure11
1.Leverpositiontopushthe
machine
3.Leverpositionfor
operatingthemachine
2.Washeroutsideofslot
4.Washerinsideslot
Toreleasethedrivewheels,movethelevertothelarger
openingoftheslot,pullitoutuntilthewasherisoutsidethe
frame,thenmovetheleverbacktothenarrowportionofthe
slot.Repeatthisoneachsideofthemachine.
Releasetheparkingbraketoallowyoutopushthemachine
byhand.
Important:Donottowthemachine.
Toresetthedrivesystembacktotheoperatingposition,move
thelevertothelargeropeningoftheslot,pushinwarduntil
thewasherisinsidetheframe,thenmovetheleverbackto
thenarrowportionoftheslot.Repeatthisoneachsideof
themachine.
Specications
Height
132cm(52inches)
Length
162cm(64inches)
Width
121cm(48inches)
AerationWidth
76cm(30inches)
Coringrange5to13cm(2to5inches)
Weight
460kg(1,015lb)
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
OilType:Detergentoil(APIserviceSJorhigher)
Oilviscosity:Refertothetablebelow.
Figure12
Important:Donotoperatetheenginewiththeoillevel
belowtheLow(orAdd)markonthedipstick,orover
theFullmark.
1.TurnthekeyintheignitionswitchtotheOFFposition,
removethekey,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition
2.Allowtheenginetocool.
3.Checktheengine-oillevelasshowninFigure13.
