Figure24
1.Jackingbolts
2.Cab-jacktube
12.Attherear-mountingpoints,securethecabtothe
machinewithabolt(1/2x3inch),steelwasher(1/2x
2–1/2inch),rubberwasher(1/2x2–1/2inches)and
nut(1/2inch)asshowninFigure25.
13.Tightenallfourcab-mountingboltsuntiltherubber
mountsarecompressedtoathicknessof7/8inch.
Figure25
1.Rubbermount2.Measurementarea—22
mm(7/8inch)
14.Tightentheboltsandnutssecuringtherear-cab
mountstotheROPSposts(Figure26).
15.Adjusttheoorjackiftheboltsarebindingand
difculttoremove.
Figure26
1.Cabmount3.ROPSpost
2.Boltsandnuts
16.Loosenthejackingboltsandremovethecab-jacktube
fromthecutoutsinthecaboor(Figure27).
23
