Toro 39678 - Stopping the Machine; Adjusting the Flow Baffle

g000211
Figure9
1.Lowercontrol
bar—engagedandthe
machinegoingreverse
3.Lowercontrol
bar—engagedandthe
machinegoingforward
2.Pulluptoassistthe
machine.
DrivingBackwardupaCurb
1.Disengagethemowerblades.
2.SelecttheREVERSEpositiontodrivethe
machine.
3.Drivethemachineuntilthedrivewheelscontact
thecurb(Figure9).
Note:Bothdrivewheelsshouldcontactthe
curbandthecasterwheelsshouldbestraight.
4.Atthesametime,engagethelowercontrolbar
andliftupthelowerhandle(Figure9andFigure
10).
Note:Liftingupthelowerhandleassistswith
drivingthemachineupacurbandnotspinning
thedrivewheels.
g001452
Figure10
1.Lowercontrol
bar—engaged
2.Handle
StoppingtheMachine
CAUTION
Youorbystandersmaybeinjuredifyoumove
orattempttooperatethemachinewhileitis
unattended.
Alwaysremovetheignitionkeyandengage
theparkingbrakeifyouleavethemachine
unattended.
1.Pullbacktheuppercontrolbarandreleasethe
blade-controlbail.
2.Engagetheparkingbrake.
3.TurntheignitionkeytotheOFFpositionand
removethekey.
AdjustingtheFlowBafe
Youcanadjustthemowerdischargeowfordifferent
typesofmowingconditions.Positionthecamlock
andbafeforthebestqualityofcut.
1.DisengagethePTOandengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Loosenthenut(Figure11).
4.Adjustthebafeandnutintheslottothedesired
dischargeow.
5.Tightenthenut.
17
