Machines with a standard hour meter only
decal121-7551
121-7551
1. Power takeof f (PT O) 4. Continuous variable
setting
2. Choke 5. Slow
3. Fast
Machines with a smart hour meter only
g2241 14
126-5641
1. PT O 4. Operator-presence switch
2. Parking brake
5. See user ’ s guide for
operating condition code
3. Neutral
Machines with a Kawasaki Engine Only
decal1 14-4466
1 14-4466
1. Main, 25A
3. Charge, 25A
2. PT O, 10A
4. Auxiliary , 15A
Machines with a Kohler Engine Only
decal126-7875
126-7875
1. Fuse location 4. Auxiliary , 15A
2. Relay location
5. Start relay
3. Main, 20A 6. Not used
1 1
