Controls System
Maintenance
Adjusting the
Control-Handle Position
There are 2 height positions for the control
levers—high and low . Remove the bolts to adjust the
height for the operator .
1. Park the machine on a level surface, disengage
the blade-control switch (PT O), and engage the
parking brake.
2. Shut of f the engine, remove the key , and wait
for all moving parts to stop before leaving the
operating position.
3. Loosen the bolts and ange nuts installed in the
levers ( Figure 105 ).
4. Align the levers in the front-to-rear position by
bringing the levers together to the N EUTRAL
position, and slide them until they are aligned,
then tighten the bolts ( Figure 106 ).
g009040
Figure 105
1. Bolt (2) 3. Control lever
2. Handle
4. Nut (2)
g009195
Figure 106
5. If the ends of the levers hit against each
other , refer to Adjusting the Motion-Control
Neutral-Lock Pivot ( page 73 ) .
6. Repeat to adjust the control levers.
Adjusting the
Motion-Control Linkage
Located on either side of the machine, below the seat,
are the pump-control linkages. Rotating the end nut
with a 1/2-inch deep socket wrench allows ne tuning
adjustments so that the machine does not move in
neutral. Any adjustments should be made for neutral
positioning only .
W ARNING
The engine must be running and the drive
wheels turning so that you can perform the
adjustments. Contact with moving parts or
hot surfaces may cause personal injury .
Keep your ngers, hands, and clothing clear
of rotating components and hot surfaces.
1. Park the machine on a level surface, disengage
the blade-control switch (PT O), move the
motion-control levers to the N EUTRAL - LOCK
position, and engage the parking brake.
2. Shut of f the engine, remove the key , and wait
for all moving parts to stop before leaving the
operating position.
3. Push the deck-lift pedal, remove the height-of-cut
pin, and lower the mower deck to the ground
71
