Using the Motion-Control
Levers
g004532
Figure 24
1. Motion-control
lever— N EUTRAL - LOCK
position
4. Backward
2. Center , unlocked position 5. Front of machine
3. Forward
Driving the Machine
The drive wheels turn independently , powered by
hydraulic motors on each axle. Y ou can turn 1 side
in reverse while you turn the other forward, causing
the machine to spin rather than turn. This greatly
improves the machine maneuverability but may
require some time for you to adapt to how it moves.
The throttle control regulates the engine speed as
measured in rpm (revolutions per minute). Place
the throttle control in the F AST position for best
performance. Always operate in the full throttle
position when mowing.
W ARNING
The machine can spin very rapidly . Y ou
may lose control of the machine and cause
personal injury or damage to the machine.
• Use caution when making turns.
• Slow the machine down before making
sharp turns.
Driving Forward
Note: The engine shuts of f when you move the
traction-control with the parking brake engaged.
T o stop the machine, pull the motion-control levers
to the N EUTRAL position.
1. Disengage the parking brake; refer to
Disengaging the Parking Brake ( page 27 ) .
2. Move the levers to the center , unlocked position.
3. T o go forward, slowly push the motion-control
levers forward ( Figure 25 ).
g008952
Figure 25
Driving Backward
1. Move the levers to the center , unlocked position.
2. T o go backward, slowly pull the motion-control
levers rearward ( Figure 26 ).
29
