Positioning the Flow Bafe
For Machines with Side Discharge
The following gures are recommendations only .
Adjustments vary by grass type, moisture content,
and the height of the grass.
Note: If the engine power draws down and the
mower ground speed is the same, open the baf e.
Position A
This is the fully-rear position. The suggested use for
this position is as follows:
• Short, light grass mowing conditions
• Dry conditions
• Smaller grass clippings
• Propels grass clippings farther away from the
mower
g295810
Figure 35
Position B
Use this position when bagging. Always align it with
the blower opening.
g29581 1
Figure 36
Position C
This is the fully-forward position. The suggested use
for this position is as follows:
• T all, dense grass mowing conditions
• W et conditions
• Lowers the engine-power consumption
• Allows increased ground speed in heavy conditions
