Machines with Side Discharge Only

decal131-1 180

131-1 180

1. Read the Operator's

Manual .

3. Bagging setting

2. Short, light grass; dry

conditions

4. T all, dense grass; wet

conditions

Machines with Side Discharge Only

decal136-5508

136-5508

1. Belt routing
