CheckingtheMowerDeckFront-to-Rear
Pitch
1.Adjustthetirepressureinthereartirestothecorrect
specications.
2.Position1bladefront-to-rear.MeasureatAandB
locationsfromalevelsurfacetothecuttingedgeof
thebladetips(Figure85).
Note:Themowerbladeshouldbe6mm(1/4inch)
lowerinfrontatAthanintherearatB.
3.Rotatethebladesandrepeatforotherblades.
Figure85
1.Measurethebladeat
pointsAandB
2.Measurefromalevel
surface
4.Ifthefront-to-rearpitchisnotcorrect,refertoLeveling
theMowerDeckfromFronttoRear(page54).
LevelingtheMowerDeckfromFrontto
Rear
1.Loosenthejamnutandsideboltintheyokesthatyou
wanttoadjust(Figure86).
Figure86
1.Topbolt
4.Sidenut
2.Jamnut5.Adjusttheseyokesto
adjustthefrontsideofthe
mowerdeck.
3.Yoke6.Adjusttheseyokesto
adjusttherearsideofthe
mowerdeck.
2.Rotatethetopboltoftheyokestoadjusttheheightof
themowerdeck(Figure86).
Note:Rotatetheboltclockwisetoraisethedeck;
rotatetheboltcounterclockwisetolowerit.
3.Tightenthejamnutsandsidebolts.
4.Checkthefront-to-rearpitch;refertoCheckingthe
MowerDeckFront-to-RearPitch(page54).
