ENGINE
4-4 GT Series Tractors Service Manual
4
17. Remove the fuel cap. Slide the hose clamp down the
IXHOOLQH5HPRYHWKHIXHOOLQHIURPWKHIXHO¿OWHUDQG
drain the fuel into a suitable container. Slide the fuel
OLQHEDFNRQWRWKHIXHO¿OWHUDQGSRVLWLRQWKHKRVH
clamp to secure. Replace the fuel cap onto the fuel
tank (Fig. 398).
Fig 398 PICT-7300
20. Remove the nut securing the positive wire to the
starter assembly. Remove the positive wire from the
starter assembly (Fig. 401).
19. Disconnect the wire harness from the engine (Fig.
400).
18. Slide the other hose clamp down the fuel line and
VOLGHWKHIXHOOLQHRIIWKHIXHO¿OWHU)LJ
Fig 401 PICT-7610
Fig 400 PICT-7605
Fig 399 PICT-7603a
