ENGINE
4-10 GT Series Tractors Service Manual
4
3. Remove the bumper (Fig. 420).
Fig 420 PICT-7417
4. Remove the 4 screws securing the left and right side
bumper brackets to the frame (2 on the left and 2 on
the right) (Fig. 421).
Fig 421 PICT-7423
Throttle & Choke Cable Adjustment
7KHKRRGIURQWEXPSHUDQGPXIÀHUDVVHPEO\PXVWEH
removed to make this adjustment. To remove them,
follow steps 1 – 5. If they have already been removed,
begin at step 6.
1. Remove the hood. Refer to “Hood Removal” on
page 3-34.
2. Remove the 2 screws securing the bumper to the
frame (1 bolt on the left and 1 on the right) (Fig.
419).
Fig 419 PICT-7245
